Community High Power 12 Inch 2-Way 120 X 60 IP8-1122/26B

Community IP8-1122/26B High Power 12 Inch 2-Way 120 X 60 Black

Professional-Grade Performance, Elegant Design

The Community Pro I SERIES Point Source 800 loudspeaker delivers high-performance sound with unmatched clarity, modular flexibility, and rugged construction—ideal for both indoor and weather-resistant outdoor applications. Designed for system integrators, this speaker is optimized for modern performance venues with rotatable coverage patterns, precision waveguides, and a versatile mounting system.

Key Features

• Q-Optimized Coverage: 120° x 60° rotatable HF waveguide for focused, smooth off-axis response

• Powerful & Precise: 12" neodymium LF driver with 3" voice coil + ketone polymer HF driver for accurate, distortion-free output

• High Output Capacity: Continuous 800W passive power handling (3200W peak)

• Dual Operating Modes: Selectable Passive or Biamp with DSP for flexible integration

• Modular Rigging: 15 M10 rigging points + low-profile bracket systems for fast, clean installs

Sound You Can Trust

• Matched MF/HF ketone polymer diaphragms for a seamless tonal balance

• Demodulation rings and neodymium motors for reduced distortion and harshness

• Signature Community voicing for intelligibility and articulate reproduction in all environments

Built for Any Environment

• Indoor or Outdoor Rated: IP55W certified with MIL-STD-810G durability

• Outdoor model includes sealed gland nut and 12ft SJOW cable

• Rugged birch plywood trapezoidal enclosure with a clean, discreet finish

Applications

• Houses of Worship

• Performing Arts Centers

• Auditoriums & Theaters

• Arenas & Stadiums

• Theme Parks

• Restaurants, Nightclubs & Entertainment Venues

• Corporate AV & Meeting Spaces

Specifications at a Glance

• Operating Range: 43 Hz – 18.5 kHz

• Nominal Beamwidth: 120° x 60° (rotatable)

• SPL Output: Peak up to 130 dB

• Sensitivity: 93–105 dB depending on mode

• Enclosure: Trapezoidal birch plywood

• Weight: 55 lbs. (24.9 kg)

• Dimensions: 28" H x 14.5" W x 17.7" D (711 x 368 x 450 mm)

Included

• Community I SERIES 800 Loudspeaker

• Optional indoor or weather-resistant wiring interfaces

• User documentation

Engineered for clarity. Designed for flexibility. Built to perform.
The Community I SERIES Point Source 800 is the go-to solution for venues demanding superior intelligibility, modularity, and reliability.
