Community Medium Power 12-inch Two-Way Installation Loudspeaker - 90x40 IP6-1122/94B

Community IP6-1122/94B – 12" Two-Way Installation Loudspeaker (600W, 90° x 40° Coverage)

The Community IP6-1122/94B is a premium 12-inch two-way loudspeaker delivering exceptional pattern control, clarity, and musical detail in a compact, versatile format. Featuring a rotatable 90° x 40° waveguide, 600W continuous power handling, and selectable passive or biamp operation, this model is designed for permanent installation in performance venues, houses of worship, theaters, educational facilities, and commercial spaces.

Engineered as part of the I SERIES Point Source 600, the IP6-1122/94B features a rugged birch plywood enclosure, high-efficiency ferrite drivers, and wide compatibility with Community’s low-profile modular bracket systems for fast and clean installations.

Key Features

• 600W continuous / 2400W peak power handling

• Rotatable 90° x 40° waveguide for precise horizontal or vertical mounting

• 12" long-excursion ferrite LF driver with 2.5" voice coil

• 1.4" exit HF compression driver with 3" titanium/polyimide diaphragm

• Selectable passive or biamp operation via rear panel

• Advanced crossover design with consistent voicing across the I SERIES

• Compact trapezoidal enclosure with elegant styling and rugged construction

• Weather-resistant IP55W-rated option for outdoor use

• Compatible with indoor and outdoor rigging systems (15 × M10 inserts)

Technical Specifications

Performance

• Operating Range: 38 Hz – 17.5 kHz

• Nominal Impedance: 8Ω

• Sensitivity (@1W/1m):

  • Passive: 95 dB

  • LF: 95 dB

  • HF: 105 dB

• Max SPL:

  • Passive: 129 dB peak / 123 dB continuous

  • Equalized System: 127 dB peak / 121 dB continuous

  • HF only: 130 dB peak / 124 dB continuous

Power Handling

• Passive: 600W continuous / 2400W peak

• LF (biamp): 500W continuous / 2000W peak

• HF (biamp): 75W continuous / 300W peak

• Recommended Amplifiers:

  • Passive: 600W–1200W @ 8Ω

  • LF: 500W–1000W @ 8Ω

  • HF: 75W–150W @ 8Ω

Drivers

• LF: 1 × 12" ferrite woofer with 2.5" voice coil

• HF: 1 × 1.4" exit compression driver with 3" voice coil and hybrid diaphragm

Coverage

• Nominal Beamwidth: 90° (H) × 40° (V), rotatable

• Waveguide: 13" (330 mm) high-definition constant-directivity

Construction & Connectivity

• Enclosure: Solid birch plywood, black finish

• Input (Indoor): (2) 6-position screw terminal blocks

• Input (Outdoor): Sealed gland nut with 12 ft (3.6 m) 14 AWG SJOW cable

• Mounting: (15) M10 threaded rigging points

• Weather Rating: IP55W (IEC 60529, MIL-STD-810G compliant)

Dimensions & Weight

• Height: 28.00" (711 mm)

• Width: 14.50" (368 mm)

• Depth: 17.70" (450 mm)

• Weight: 65.0 lbs (29.5 kg)

What’s in the Box

• (1) Community IP6-1122/94B Loudspeaker

• (1) Documentation Packet

Recommended for: Installations needing narrow vertical and wide horizontal coverage in acoustically complex spaces—such as theaters, churches, multipurpose halls, and distributed sound systems requiring focused control and high fidelity.
