Community Medium Power 12-inch Two-Way Installation Loudspeaker - 120x60 IP6-1152/26B

Community IP6-1152/26B – 15" Two-Way Installation Loudspeaker (600W, 120° x 60° Coverage)

The Community IP6-1152/26B is a powerful and versatile 15-inch two-way loudspeaker featuring a 120° x 60° rotatable waveguide, designed to deliver wide-area coverage with consistent performance. Built for both indoor and weather-resistant outdoor installations, this model is ideal for professional audio integrators seeking high-output, full-range fidelity in a compact, elegant form factor.

Engineered within the I SERIES Point Source 600 family, the IP6-1152/26B is optimized for performance venues including stadiums, auditoriums, houses of worship, and multipurpose halls. Its combination of exceptional dispersion, deep LF extension, and low distortion makes it a go-to solution for high-demand environments.

Key Features

• 600W continuous / 2400W peak power handling

• 120° x 60° rotatable HF waveguide for wide, even coverage

• 15" ferrite LF driver with 3" voice coil for extended low-frequency response

• 1.4" exit HF driver with 3" titanium/polyimide diaphragm for articulate highs

• Selectable passive or biamp operation for system design flexibility

• Weather-resistant IP55W rating with PolyGlas option for demanding outdoor use

• Modular rigging options for clean and efficient installation

Technical Specifications

Acoustic Performance

• Frequency Range: 30 Hz – 17.5 kHz

• Sensitivity (@1W/1m):

  • Passive: 94 dB

  • LF: 95 dB

  • HF: 104 dB

• Maximum SPL:

  • Passive: 128 dB peak / 122 dB continuous

  • Equalized System: 127 dB peak / 121 dB continuous

Power Handling & Impedance

• Nominal Impedance: 8 ohms

• Passive: 600W continuous / 2400W peak

• LF (biamp): 500W continuous / 2000W peak

• HF (biamp): 75W continuous / 300W peak

• Recommended Amps:

  • Passive: 600–1200W @ 8Ω

  • LF: 500–1000W @ 8Ω

  • HF: 75–150W @ 8Ω

Driver Configuration

• LF: 1 × 15" (381 mm) ferrite cone driver, 3" (76 mm) voice coil

• HF: 1 × 1.4" (36 mm) exit compression driver, 3" (76 mm) hybrid diaphragm

Coverage & Waveguide

• Beamwidth: 120° (H) × 60° (V), rotatable

• HF Waveguide: 13" (330 mm), constant-directivity

Enclosure & Connections

• Material: Birch plywood, trapezoidal form, black finish

• Mounting: 15 × M10 threaded rigging points

• Indoor Input: (2) 6-position screw terminal blocks

• Outdoor Input: Sealed gland nut with 12 ft (3.6 m) 14 AWG SJOW cable

• Environmental Rating: IP55W (IEC 60529 / MIL-STD-810G)

Dimensions & Weight

• Height: 30.80" (782 mm)

• Width: 16.50" (419 mm)

• Depth: 20.07" (510 mm)

• Weight: 79 lbs (35.8 kg)

What’s Included

• (1) Community IP6-1152/26B Loudspeaker

• (1) User Documentation Packet

Ideal For: Permanent installs where wide-angle coverage and high SPL are essential — including sports venues, public assembly spaces, large-scale performance halls, and outdoor AV systems.
