Titan Weatherproof AV Series 12Port/8POE+ Managed Switch

Titan Weatherproof Luxul AV Series 12Port / 8POE+ Managed Switch

This high-performance 12-Port Gigabit Managed Switch is designed for reliable and efficient expansion of modern networks, especially those using PoE-enabled devices such as VoIP phones, IP cameras, and wireless access points. With advanced Layer 3 static routing, silent fanless operation, and a 130W PoE+ power budget, it combines intelligent power control with enterprise-level flexibility.

Key Features

• 8 × PoE+ Gigabit RJ45 Ports (802.3af/at) with 130W total PoE power budget

• 2 × Gigabit SFP ports for fiber uplinks

• 2 × Non-PoE Gigabit RJ45 ports

• PoE Self-Healing with auto-recovery and power scheduling

• Layer 3 static routing support

• 802.1Q VLAN with trunking and QoS

• 24 Gbps switching capacity

• Fanless design for silent operation

• Plug-and-play installation with intuitive management

• Selectable green or blue LED indicators

• Surge protection tested to EN61000-4-5 (RJ45 port, 6kV)

• Standard 19” rack-mountable form factor

Technical Specifications

Interfaces

• 10 × Gigabit RJ45 Ports

• 2 × Gigabit SFP Ports

• Ethernet Cable Compatibility:

  • 10Base-T: Cat 5 UTP/STP

  • 100Base-TX: Cat 5 UTP/STP

  • 1000Base-T: Cat 5, 5e, or 6 UTP/STP

• Cable Auto-Sensing: Straight-through or Crossover

Power

• Internal Switched Power Supply

• Input: AC 100–240V, 50–60Hz

• PoE Power Budget: 130 Watts Max

• Total Max Power Consumption: 168 Watts

Performance

• Switching Capacity: 24 Gbps

• Network Speeds:

  • 10Mbps Half / 20Mbps Full

  • 100Mbps Half / 200Mbps Full

  • 1000Mbps Full (Gigabit)

• VLAN Support:

  • IEEE 802.1Q

  • Up to 4094 VLAN IDs

  • 1 Management VLAN

Certifications

• CE, FCC, RoHS Compliant

Physical Specifications

• Dimensions: 17.3” x 8.25” x 1.75”

• Weight: 6.2 lb

What’s in the Box

• 12-Port / 8 PoE+ Gigabit Managed Switch

• Power Cord

• Rack Mount Kit

• Quick Install Guide

Ideal for: Office networks, security camera systems, VoIP deployment, and scalable WiFi installations where PoE+ and silent performance are essential.
